PPR Pipe Manufcturer

PPR (polypropylene random copolymer) refers to plastic pipes made of polypropylene random copolymer plastic, which can be used to provide cold water as well as heating systems.

WhatsApp Inquiry Now

Product Features Application Areas Specification & Dimension

Product Features

1. Low thermal conductivity, the temperature outside the PPR pipe will not affect the liquid inside the pipe.
2. High temperature resistance, pipe PPR can withstand a high temperature of 95°C and is suitable for hot water supply systems.
3. Corrosion resistance, PPR pipes are resistant to corrosion by acidic or alkaline substances.
4. Light weight, easy to install, easy to transport, cut and connect.

Application Areas

1. Hot and cold water supply and sewage treatment systems for residential, commercial and industrial buildings
2. Heating systems
3. Industrial piping systems
4. Agricultural irrigation
5. Chemical and fluid transportation

Specification & Dimension

PPR Pipe Specification	PN12.5(1.25Mpa)/(S5)					PN16(1.6Mpa)/(S4)
	Specification	Unit	Number of Packing	Unit(g)	Packing Volume	Specification	Unit	Number of Packing	Unit(g)	Packing Volume
	20*2.0	m	200	115	0.092	20*2.3	m	200	132	0.092
	25*2.3	m	140	165	0.092	25*2.8	m	140	198	0.092
	32*3.0	m	80	268	0.092	32*3.6	m	80	318	0.092
	40*3.7	m	60	410	0.092	40*4.5	m	60	485	0.092
	50*4.6	m	40	626	0.092	50*5.6	m	40	760	0.092
	63*5.8	m	24	968	0.092	63*7.1	m	24	1310	0.092
	75*6.9	m	24	1350	0.092	75*8.4	m	24	1690	0.092
	90*8.2	m	16	2000	0.092	90*10	m	16	2450	0.092
	110*10	m	12	2980	0.092	110*12.1	m	12	3650	0.092
PPR Pipe Specification	PN20(2.0Mpa)/(S3.2)					PN25(2.5Mpa)/(S2.5)
	Specification	Unit	Number of Packing	Unit(g)	Packing Volume	Specification	Unit	Number of Packing	Unit(g)	Packing Volume
	20*2.8	m	200	152	0.092	20*3.4	m	200	172	0.092
	25*3.5	m	140	225	0.092	25*4.2	m	140	250	0.092
	32*4.4	m	80	365	0.092	32*5.4	m	80	417	0.092
	40*5.5	m	60	568	0.092	40*6.7	m	60	680	0.092
	50*6.9	m	40	890	0.092	50*8.4	m	40	1050	0.092
	63*8.6	m	24	1430	0.092	63*10.5	m	24	1750	0.092
	75*10.1	m	24	2050	0.092	75*12.5	m	24	2400	0.092
	90*12.3	m	16	3050	0.092	90*15	m	16	3450	0.092
	110*15.1	m	12	4100	0.092	110*18.3	m	12	4900	0.092
